fischer Channel bolt FBC-S-38/23-M16x30-8.8 HDG

Top Features

Only for hot-rolled profiles with serration.
All directional load capacity.
Qualified load capacity in channel longitudinal direction to prevent bolt slide risks.
Marked on bolt tip with two staggered grooves.
Steel grade: 8.8.

Serrated channel bolt for optimum strength and safety.

Advantages

FBC-S bolts with serrated underside perfectly interlock with channels with serrated lips.
Thus giving optimum load capacity with high safety.
All directional load capacity.
Plus optimum load capacity in longitudinal direction in combination with FES-H-S due to the full serration of the system.
Ideal prepositioned fixing solution, capable of covering on-site tolerances.
Suitable for applications in cracked and non-cracked concrete.
Permanently adjustable fixing solution.

Serrated T-Bolt which in combination with the matching fully serrated channel creates precise mechanical interlocking.

Properties

ETA-approval
Thread ( M )	M16
Diameter ( d )	16 mm
Steel grade	8.8
Length ( l )	30 mm
Length channel bolt head ( b_cbo,1 )	16,7 mm
Width ( b_cbo2 )	29,1 mm
Height ( t_cbo )	5,8 mm
Min. spacing channel bolts ( s_cbo )	80 mm
Match	FES-H-S-38/23
Profile	FBC-S-38/23
Material	Hot-dip galvanised steel grade 8.8
Amount	50 pcs
GTIN (EAN-Code)	4048962523188
